1/1
|
* Nominal Voltage (V): ::
|
48V
|
|
* Nominal Capacity (Ah):
|
15Ah
|
|
* Source Resistance (mΩ):
|
40mΩ
|
|
* Cell Combination:
|
1-parallels
|
|
13-series
|
|
|
*Cell Quantity (parallel*series): )
|
13 pcs
|
|
* Discharge Cut off Voltage (V):
|
26V
|
|
* Charge Cut off Voltage (V):
|
54V
|
|
* Max Discharge Current (A):
|
50A
|
|
* Max Continuous Discharge Current (A):
|
30A
|
|
* Charge Mode:
|
CC-CV
|
|
* Standard Charge Current (A):
|
2.0A
|
|
* Charge Time under Standard Charge Current
|
6 hours
|
|
* Charge Temperature Range:
|
-20-55°C
|
|
* Discharge Temperature Range:
|
-20-55°C
|
|
* Charging Cycles:
|
>2000 times
|
|
* Dimensions:
|
363mm L × 150 mm W × 84 mm H HHHh h
|
|
* Battery Net Weight:
|
5.75 kgs
|
|
* Battery Gross Weight(with all parts and package):
|
6.2 kgs
|
